Unifi Routing & Switching
Ubiquiti (US-16-150W-AU) Ubiquiti UniFi Switch 16-port Managed PoE+ Gigabit Switch with SFP, 150W PoE Budget, GEN1

Ubiquiti (US-16-150W-AU) Ubiquiti UniFi Switch 16-port Managed PoE+ Gigabit Switch with SFP, 150W PoE Budget, GEN1

Ubiquiti

$513.22

$465.70

(You save $47.52 )

Quantity

SKU:: US-16-150W-AU
UPC:
Availability:: Contact Us for Availability

Layer 2, PoE switch with (16) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports and (2) 1G SFP ports.

The Switch 16 PoE 150W (US 16 PoE 150W), a fully managed switch with (16) GbE RJ45 ports and (2) 1G SFP ports. Each of the switch's ports can provide either 802.3at PoE+ or configurable, 24V passive PoE to UniFi access points or other PoE devices. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

(16) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports
(2) 1G SFP ports
122W total PoE supply

Managed with the UniFi Network application

US-16-150W
Dimensions	443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
Weight Rack-Mount Brackets Excluded Rack-Mount Brackets Included	2.80 kg (6.17 lb) 2.89 kg (6.37 lb)
Networking Interfaces	(16) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports
Management Interface	Ethernet In-Band
Total Non-Blocking Throughput	18 Gbps
Switching Capacity	36 Gbps
Forwarding Rate	26.78 Mpps
MAC Address Table	16384
Maximum Aggregations	6
Monitoring Sessions	1
Maximum VLANs	255
Power Method	100-240VAC/50-60 Hz, Universal Input
Power Supply	AC/DC, Internal, 150W DC
Max. Power Consumption Including PoE Output Excluding PoE Output	150W 28W
LEDs Per Port RJ45 Data Ports SFP Data Ports	PoE, Speed/Link/Activity Speed/Link/Activity
Sound Level* Fan Level: 0 Fan Level: 1, 2, 3	1.7 dBr 10.8 dBr
ESD/EMP Protection	Air: ?? 24 kV, Contact: ?? 24 kV
Shock and Vibration	ETSI300-019-1.4 Standard
Operating Temperature	-5 to 40?? C (23 to 104?? F)
Operating Humidity	5 to 95% Noncondensing
Certifications	CE, FCC, IC
PoE+ Per Port
PoE Interfaces	PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-)
Max. PoE+ Wattage per Port by PSE	34.2W
Voltage Range 802.3at Mode	50?û57V
Max. Passive PoE Wattage per Port	17W
24V Passive PoE Voltage Range	20-27V

Instructions and Manuals

Datasheet

Quick Start Guide
