Dimensions
Ø 48.50 x 159.49 mm (1.90 x 6.28")
Weight: 315 g (0.69 lb)
System Requirements
UniFi Cloud Key or Dream Machine, or machine running Linux, Mac OS X, or Windows 7/8/10
Package Contents
UniFi AP FlexHD
Base Mount, Outdoor Mount, Wall/Pole Mount, PoE Adapter* (48V, 0.32A), Power Cord, Plastic Ties (Qty. 2), Screws (Qty. 2), Screw Anchors (Qty. 2)
Technical Specifications
Network Interfaces
Networking: (1) 10/100/1000 Ethernet Port
Management: Ethernet, Wi-Fi
Power
Max. Power Consumption: 10.5W
Power Method: 802.3af
Power Supply: 802.3af, 48V, 0.32A Gigabit PoE Adapter
Supported Voltage Range: 44 - 57VDC
Wi-Fi
Wi-Fi Standards: 802.11 a/b/g/n/ac/ac-wave2
Wireless Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Environment
Operating Temperature: -30 to 70° C (-22 to 158° F)
Operating Humidity: 5 to 95% Noncondensing
Button
Reset
LED
System / Status
Antenna Gain
2.4 GHz: 1.6 dBi
5 GHz: 4 dBi
Mounting
Ceiling/Pole/Tabletop/Wall
Certifications
CE, FCC, IC
