Rack-mountable, Gigabit switch with (12) SFP ports and (4) Gigabit RJ45 ports.
Advanced Switching Technology for the Masses Build and expand your network with Ubiquiti EdgeSwitch?« Fiber, part of the EdgeMAX?« line of products. The EdgeSwitch Fiber is a fully managed, Gigabit fiber switch, delivering robust performance and intelligent switching for high?bandwidth networks. The EdgeSwitch Fiber offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.
Features:
- (12) Gigabit SFP Ports
- (4) Gigabit RJ45 Ports
- (1) Serial Console Port
- Non-Blocking Throughput: 16 Gbps
- Switching Capacity: 32 Gbps
- Forwarding Rate: 23.81 Mpps
- Maximum AC Power Consumption: 56W
- Rackmountable with Rack-Mount Brackets (Included)
- DC Input Option (Redundant or Stand-Alone)
| EdgeSwitch 12F | |
|---|---|
| Dimensions | 443 x 221 x 43 mm (17.44 x 8.70 x 1.69") |
| Weight Rack-Mount Brackets Included Rack-Mount Brackets Excluded | 2.68 kg (5.91 lb) 2.59 kg (5.71 lb) |
| Total Non-Blocking Line Rate | 16 Gbps |
| Max. AC Power Consumption | 56W |
| Power Method AC DC | 100-240VAC/50-60 Hz, Universal Input DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector |
| Power Supply | AC/DC, Internal, 56W DC |
| Supported Voltage Range | 100 to 240VAC 25 to 16VDC |
| LEDs Per Data Port | Speed/Link/Activity |
| Networking Interfaces | (8) 100/1000 Mbps SFP Ethernet Ports (4) 1000 Mbps SFP Ethernet Ports (4) 10/100/1000 Mbps RJ45 Ethernet Ports |
| Management Interface | (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band |
| Rackmount | Yes, 1U High |
| ESD/EMP Protection | Air: ?? 24 kV, Contact: ?? 24 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40?? C (23 to 104?? F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
