| Description | |
| Manufacturer: | Cisco Systems, Inc |
| Manufacturer Part Number: | HWIC-4T1/E1= |
| Manufacturer Website Address: | http://www.cisco.com/c/en_au |
| Brand Name: | Cisco |
| Product Name: | 4 Port Clear Channel T1/E1 High Speed WAN Interface Card |
| Marketing Information: | Reduced Footprint If you are using multiple 1- or 2-port T1/E1 modules for n x T1/E1 connectivity, you can now replace the modules with a single Cisco 4-Port Clear Channel T1/E1 HWIC, and you can make the HWIC slots available for other interfaces and services. If you use a single T1/E1 today and plan to scale up to 4 T1/E1 modules in the future, you can install the 4-port HWIC today and turn on the additional T1/E1 ports as you need them. Deployment Flexibility The Cisco 4-Port Clear Channel T1/E1 HWIC is software-configurable between E1 or T1 operation, balanced or unbalanced E1 termination, and CSU/DSU. You no longer need to buy a specific module for T1 support and then another card for E1 connectivity. If you have branch offices across the world, ordering, inventory and management are much simplified. |
| Product Type: | HWIC |
| Technical Information | |
| Application/Usage: | Wide Area Network |
| Interfaces/Ports | |
| Total Number of Ports: | 4 |
| Connector Type: | RJ-48C |
| Interfaces/Ports Details: | 4 x RJ-48C T1/E1 WAN |
| Media & Performance | |
| Network Technology: | T1/E1 |
| Maximum Data Transfer Rate: | 2.048 |
| Physical Characteristics | |
| Height: | 19.1 mm |
| Width: | 78.2 mm |
| Depth: | 120.4 mm |
| Weight (Approximate): | 90.7 g |
| Miscellaneous | |
| Compatibility: | Cisco Integrated Services Routers:
|
| Warranty | |
| Limited Warranty: | 90 Day |
